Woltman Turbine Meter

Product Details:

Share Your Product:

Request To Call Back Send Inquiry

Woltman Turbine Meter Price And Quantity

Product Description

Being the leading names in the industry, our company is regarded as one of the well established manufacturers and exporters of Woltman Turbine Meter. These turbine meters are manufactured under the strict guidance of our professional using tested quality components and innovative technologies. These turbine meters are automatic in nature in compliance with set quality guidelines. Available in different capacity, these turbine meters are used to measure the flow rate of water passing through pipelines. Our Woltman Turbine Meter is easy to use and are highly sensitive.

Technical Parameters

Nominal Diameter (DN)		Unit	Single-jet		Multi-jet
		mm	15	20	15	20	25	40	50
		Inches	1/2	3/4	1/4	3/4	1	1 1/2	2
Starting Flow Rate		I/h	14	18	14	18	25	70	80
Maximum Admissible Temp.		C	45 C (Optional 90C)
Maximum Admissible Working Pressure		bar (kg/cm3)	10
Test Pressure - P		bar (kg/cm2)	16
Qmax	Max. Peak flow +- 2% Accuracy	m3/hr	3.0	5.0	3.0	5.0	7.0	20.0	30.0
Qn	Nominal flow +- 2% Accuracy	m3/hr	1.5	2.5	1.5	2.5	3.5	10.0	15.0
Qt.	Transitional flow +-2% Accuracy	I /h	120	200	120	200	280	800	1200
Qmin	Minimum flow +- 5% Accuracy	I / h	30	50	30	50	70	200	300
Head Loss at	Qmax	m	7.0	7.0	6.5	7.5	9.0	5.0	4.8
Head Loss at	Qn	m	1.7	1.8	1.7	1.9	2.3	1.3	1.2
Dimension
Length (without Tail Pipes)		mm			165	190	260	300	330
Length (with Tail Pipes)		mm	250	290	250	290	380	430	470
