Multi Jet Dry Dial Water Meter Price And Quantity
- 10 Piece
Multi Jet Dry Dial Water Meter Trade Information
- Cash in Advance (CID) Cheque Cash Advance (CA)
- 1 Piece Per Day
- 1-2 Days
- Australia South America Middle East Central America Eastern Europe Western Europe Asia North America Africa
- All India
Product Description
Multi Jet Dry Dial Water Meter
25mm Multi-Jet HOT Water Meter
Salient Features
- Sealed extra dry totaliser.
- High flow-rates enduring capacities.
- Maximum corrosion protection.
- No effect by external magnetic fields.
- Measuring mechanism can be removed without interrupting water supply.
Metrological Performance and Dimensions.
| Size of Meter - mm | 50 | 65 | 80 | 100 | 150 | 200 | 250 | 300 | |
| QsQmax | Max. Peak flow, +- 2% m3/hr | 30 | 50 | 80 | 120 | 300 | 500 | 800 | 1200 |
| Q[/Qn | Nominal flow, +-2% m3/hr | 15 | 25 | 40 | 60 | 150 | 250 | 400 | 600 |
| Qt. | Transitional flow, +-2% m3/hr | 3 | 5 | 8 | 12 | 30 | 50 | 80 | 120 |
| Qmin | Minimum flow, +- 5% m3/hr | 0.45 | 0.75 | 1.20 | 1.80 | 4.50 | 7.50 | 12.00 | 18.00 |
| Overall Length mm | 200 | 200 | 200 | 250 | 300 | 350 | 450 | 500 | |
| O.D. of Flange mm | 165 | 185 | 200 | 220 | 285 | 340 | 395 | 445 | |
| Flange Thickness mm | 19 | 19 | 21 | 22 | 23 | 24.5 | 26 | 27.5 | |
| Dia of Bolt circle (PCD) mm | 125 | 145 | 160 | 180 | 240 | 295 | 350 | 400 | |
| Dia of Holes mm | 19 | 19 | 19 | 19 | 23 | 23 | 23 | 23 | |
| No. of Bolts | 4 | 4 | 4 | 8 | 8 | 8 | 12 | 12 | |
| Weight kg (Approx) | 11.4 | 12.6 | 14.1 | 19.5 | 34 | 55 | 75 | 175 | |
