Multi jet Dry Dial Meters

Product Details:

Share Your Product:

Request To Call Back Send Inquiry

Multi jet Dry Dial Meters Price And Quantity

Product Description

Holding profound knowledge in this domain, we are counted as one of the well established manufacturers and exporters of Multi jet Dry Dial Meters. To manufacture these meters in compliance with industrial standards, we procure high grade materials & components from trusted vendors of the market. Widely used in diverse industries, we are offering these meters to our esteemed clients in diverse specifications. Owing to features such as low head loss, perfect finish and accurate readings, these Multi jet Dry Dial Meters are popular in the market.

50mm Multi-Jet Water MeterSalient Features

Velocity type meter
Direct magnetic transmission
Class B ISO 4064
Superior accuracy and long-term reliability
Highly sensitive to low flow rate and very accurate over its entire flow range.
Vacuum sealed. leak proof and dry Totaliser.
Maintenance-free long working life.

Technical Parameters

Nominal Diameter (DN)		Unit	Single-jet		Multi-jet
		mm	15	20	15	20	25	40	50
		Inches	1/2	3/4	1/4	3/4	1	1 1/2	2
Starting Flow Rate		I/h	14	18	14	18	25	70	80
Maximum Admissible Temp.		C	45 C (Optional 90C)
Maximum Admissible Working Pressure		bar (kg/cm3)	10
Test Pressure - P		bar (kg/cm2)	16
Qmax	Max. Peak flow +- 2% Accuracy	m3/hr	3.0	5.0	3.0	5.0	7.0	20.0	30.0
Qn	Nominal flow +- 2% Accuracy	m3/hr	1.5	2.5	1.5	2.5	3.5	10.0	15.0
Qt.	Transitional flow +-2% Accuracy	I /h	120	200	120	200	280	800	1200
Qmin	Minimum flow +- 5% Accuracy	I / h	30	50	30	50	70	200	300
Head Loss at	Qmax	m	7.0	7.0	6.5	7.5	9.0	5.0	4.8
Head Loss at	Qn	m	1.7	1.8	1.7	1.9	2.3	1.3	1.2
Dimension
Length (without Tail Pipes)		mm			165	190	260	300	330
Length (with Tail Pipes)		mm	250	290	250	290	380	430	470
